Aranbe Heat is an Australian family owned and operated business with over 30 years in the wood heating industry. Their full range of wood heaters are designed and manufactured in Australia
Heating Capacity (sq/m) | Heater Dimensions (mm) | Min. Wall Hearth Requirements (mm) | Min. Corner Hearth Clearance (mm) | Min. Hearth Thickness (mm) | Min. Clearances (mm) | Rear of heater to centre of flue spigot (mm) | |
---|---|---|---|---|---|---|---|
ARANBE 160 | 160 | 780H x 585W x 552D | 750W x 950D | 1250W x 1250D | 6 | Rear-100 Side-400 Corner-200 | 192 |
ARANBE 160 LEGS | 160 | 780H x 585W x 552D | 750W x 950D | 1250W x 1250D | 6 | Rear-100 Side-400 Corner-200 | 192 |
ARANBE 220 | 220 | 760H x 670W x 520D | 860W x 965D | 1200W x 1200D | 6 | Rear-190 Side-250 Corner-75 | 175 |
ARANBE 240 | 240 | 815H x 667W x 565D | 830W x 985D | 1290W x 1290D | 6 | Rear-150 Side-400 Corner-225 | 220 |
ARANBE 240 LEGS | 240 | 815H x 667W x 565D | 830W x 1135D | 1350W x 1350D | 24 | Rear-225 Side-475 Corner-225 | 220 |
ARANBE 300 | 300 | 860H x 777W x 559D | 955W x 1130Dⁿ | 1350W x 1350D | 12 | Rear-350 Side-450mm Corner-200 | 200 |
ARANBE 220 INBUILT | 220 | 747H x 885W* | 885W x 300D | --- | 18 | --- | 290• |
*includes fascia | ⁿwhen installed with flue heat shield | •back of fascia to centre of flue |
